Barbed wire is a protective net formed by mechanically winding barbed wire
around the main wire through various weaving techniques.
Anti-corrosion,anti-aging,high durable.Barbed wire can be used with
chain link or other fencing barriers for added security.It can discourage
unauthorized entry and is suited to a variety of containment needs.
Mainly serves in isolation and protection of grassland,boundary,railway,highway,prisons,
private residence,bank,bill printing factory,and also widely used in military base,
industry,agriculture,animal husbandry,plantation for fencing.
Surface treatment:Electric galvanizing,hot dipped galvanizing,PVC coated or spraying plastics.
PVC color: Green,yellow,blue or other colors.
Packing: Nude packing,woven bag,wooden pallet,or as customer’ request
Weave Type | Photo |
Single twisted barbed wire Common twisted barbed wire Reverse twisted barbed wire |
![]() |
Type | Wire Gauge | Barb Distancemm | Barb Lengthmm |
Electro Galv.Hot-Dip Galv. | BWG10 x BWG12 BWG12 x BWG12 BWG12 x BWG14 BWG14 x BWG14 BWG14 x BWG16 BWG16 x BWG16 BWG16 x BWG18 BWG17 x BWG17 |
75-150 | 15-30 |
PVC Coated | Before coating: BWG11-20 After coating: BWG8-17 |
75-150 | 15-30 |
Pvc coating thickness: 0.6mm – 1.00mm
Bare packing with bulk or on pallet. With plastic film and pallet.
